ISO 1167 ASTM D1598 ASTM F1335 Plastic Pipe Hydrostatic Pressure and Burst Tester Testing Machine
Available
377Product Description ISO 1167 ASTM D1598 ISO9080 ASTM F1335 Plastic
| Model NO. | 50mm |
| Type | 0.5 |
| Load Way | Static Load |
| Display | Computer Control |
| Weight | AC380V |
| Oil Cylinder Position | Tensile Test Compression Test, Bending Test etc. |
| Packaging Details | 300kN 500kN 600kN 1000kN 1500kN 2000kN |
| Standard | Plastic Pipe |
| Certificate | Plywood Case |
| Specification | VTS |
| Origin | 9024109000 |
| Production Capacity | <1000KN |
| Max Load | Pendulum Charpy Impact Testing Machine |
| Testing Machine Mode | OEM |
| Protection Class | 0.5grade |
| Application | <900kg |
| Test Standard | 380V |
| Material | Computer, Digital, Dial |
| Impact Energy | Plastic Pipe Hydrostatic Pressure and Burst Tester |
| Testing Standard | 10MPa, 16MPa, 25MPa, 3 Stations |
| Testing Pipe |
1. Applications & functions
XGNB Series Hydrostatic/Burst Tester is used to determine the long-term hydrostatic strength and instant blasting of PVC, PE, PPR, ABS and other plastic pipes. It is under the standard of ISO 1167, ASTM D1598, ISO9080, CJ/T108 and ASTM F1335.
2. Main Features
1. Double control modes: Each station has a piece of precise pressure micro-control unit and is controlled by microcomputer. All the parameters including pressure, time and accuracy can be set by both pressure micro-control unit and pc.
2. It can display and store the total 8 parameters such as pressure, time, and status timely. It can store pressure data for 8760 hours in order to avoid losing data during the system computer offline.
3. It can judge both effective and ineffective time parameters automatically. The effective time means the time of the pressure within the setting pressure.
4. In every station, the two solenoid valves (Germany GSR) can work separately according to the test as well as the accuracy of ±0.0001Mpa.
5. One high-accuracy pressure sensor in every station, and the resolution is 0.001MPa.
6. Import Pressure station (American Giant), one set each station, performance of the test pressure pump is better than Chinese made water pressure pump and no need of air pump. Its sound is lower.
7. As we adopt distributed control method of microcomputer and PC, microcomputer may go on working without online or off PC and assure that test data are not lose (the longest 8760 hours).
8. Auto release pressure makes test more convenient and safe.
3. Main Technical Specifications:
| No | Item | |||
| 1 | Pressure range | 10Mpa | 16Mpa | 25Mpa |
| 2 | Resolution of pressure testing | 0.001MPa | 0.001MPa | 0.001MPa |
| 3 | Accuracy | Better than ±1% | Better than ±1% | Better than ±1% |
| 4 | Testing pipe | φ20mm-φ630mm | φ20mm-φ630mm | φ20mm-φ630mm |
| 5 | Test station | 3 stations or even more | 3 stations or even more | 3 stations or even more |
| 6 | Constant temp. range | room temperature~95ºC | room temperature~95ºC | room temperature~95ºC |
| 7 | Temp. Accuracy | ±0.1ºC | ±0.1ºC | ±0.1ºC |
| 8 | Time accuracy | ≤±0.1% | ≤±0.1% | ≤±0.1% |
| 9 | Power supply | 3 phase, 380v±10%, 50Hz | 3 phase, 380v±10%, 50Hz | 3 phase, 380v±10%, 50Hz |
Jinan Victory Instrument Co., Ltd (Victory Test - VTS) is a professional manufacturer and exporter of material testing machines and quality control testing equipment in Jinan city, Shandong province, China. Jinan city is the capital of Shandong province, which is located in the northeast of China (about 2 hours away from Beijing and Shanghai.) We are dedicated to offer one stop solution for customers Quality Control of metal materials. With more than 50 staffs & more than 20 years experience, a professional testing solution can be offered quickly.
VTS is an ISO9001 CE certified high-tech enterprises, who focus on designing, researching, making and marketing on metal materials mechanical property testing machines. The testing machines cover most of the testing items, like tensile, compression, bend, torsion, impact, hardness, fatigue, etc. VTS products can meet ISO, ASTM, BS EN, TAPPI, GB, etc testing standards. We have passed CE certificate, VTS products have been exported to more than 60 countries.
As we have more than 20 years experience, an ideal testing solution can be offered quickly based on your testing requirement.
Our Advantages:
As we have more than 20 years experience, an ideal testing solution can be offered quickly based on your testing requirement.
1. Professional manufacturer for more than 20 years
2. Reasonable price with good quality & best delivery time
3. One-Stop solution for material testing machines
4. ISO 9001 SGS CE etc qualified supplier
5. Lifetime technical support and service
Sale period service:
After we get your P.O., the production can be quickly arranged.
For common standard machine, it is in stock.
For customized produced machine, the production time is about 2-4 weeks.
Strictly control of quality, each machine is well inspected before delivery.
After-sales service:
The warranty period is usually one year.
English language operation manual and operation video are offered.
Onsite installation and training service can be offered if its necessary.
