Professional Pipe Opacity Tester For Industrial Use And Analysis

Product Description Pipe Opacity Tester

Color: Default Color
Size: Default Size
Origin: China
Usage: Default Usage
Type: Default Type
Efficiency: 99.9% Type

Category: Plastic and Rubber Testing Instrument

Get Inquiry

Description:

Model NO.	50mm
Type	0.5
Load Way	Static Load
Display	Computer Control
Weight	AC380V
Oil Cylinder Position	Tensile Test Compression Test, Bending Test etc.
Packaging Details	300kN 500kN 600kN 1000kN 1500kN 2000kN
Standard	Metal,Steel,Wire Rope,Rubber,Plasticcable
Certificate	Plywood Case
Specification	VTS
Origin	9024109000
Production Capacity	<1000KN
Max Load	Tensile Testing Machine
Testing Machine Mode	OEM,Software Reengineering
Protection Class	0.5grade
Application	<900kg
Test Standard	380V
Material	Computer, Digital, Dial
Impact Energy	Plastic Pipe Hydrostatic Pressure and Burst Tester
Testing Standard	10MPa, 16MPa, 25MPa, 3 Stations
Testing Pipe	+50PA~ +1500PA
Usage

Product Description

Pipe Opacity Tester

1. Applications & functions

This tester mainly used to determine the opacity of pipes and fittings. lt is an ideal device for pipe manufacturers, research and inspection institution.
The use of the pipe light transmittance tester overcomes the subjectivity of the traditional method of testing the opacity of the pipe, and then obtains the true light transmittance of the pipe. The instrument is mainly composed of light source, luminous flux acquisition system, automatic warehouse entry and exit control system, sample automatic moving device, sample rack, touch screen human-computer interaction interface and micro-printer.
It conforms to ISO 7686:2005 and the equivaient.

2. Structural features

1. Accuracy
1) Using high-precision parallel light source, the measurement result is stable and reliable;
2) The luminous flux acquisition system uses high-precision optical collectors and up to 24-bit analog-to-digital conversion circuits to make the measurement results more accurate.

2. Test operation
1) The instrument is equipped with gratings and sample holders of different sizes to adapt to pipe testing of different calibers;
2) The sample compartment is automatically in and out, and the sample installation and removal are convenient, which improves the test efficiency;
3) Automatically complete instrument calibration and three-point measurement at one time.
3. Data processing
1) Automatically save up to 1000 sets of test data;
2) Rapid test data retrieval and screening functions;
3) Use a micro-printer to print data, which is convenient for test records.
4. Display
It adopts large-size full-color LCD touch screen control and display, which is convenient to operate and intuitive to display.
5. Appearance
It adopts a unique streamlined appearance design, which is beautiful and generous.

3. Main Technical Specifications:

1) Pipe diameter range: Φ20 ~Φ40
2) Resolution: 0.01%
3) Accuracy: < 0.05%
4) Power supply: (220-15% ~220+10%) VAC 50Hz 500W
5) Host size (length x width x height): 460mm x 240mm x 510mm
6) Host weight: about 30Kg

Jinan Victory Instrument Co., Ltd. (Victory Test - VTS) stands as a beacon of excellence in the realm of material testing machines and quality control testing equipment. Nestled in the vibrant city of Jinan, the capital of Shandong province in China, VTS is strategically positioned in the northeast, just a short journey from both Beijing and Shanghai. Known for its professionalism in both manufacturing and exporting, VTS has solidified its reputation for delivering top-notch testing solutions. Our unwavering commitment is to provide a comprehensive, one-stop solution for the Quality Control of metal materials. Backed by a robust team of over 50 dedicated professionals and enriched by more than two decades of industry expertise, we are poised to deliver professional testing solutions with unmatched speed and precision.

Victory Test Systems (VTS) proudly upholds the highest standards as an ISO9001 and CE certified high-tech enterprise. Our core competency lies in the design, research, manufacturing, and marketing of cutting-edge metal materials mechanical property testing machines. These versatile machines are meticulously crafted to handle a broad spectrum of testing requirements including tensile, compression, bending, torsion, impact, hardness, fatigue, and more. Each product adheres to globally recognized standards such as ISO, ASTM, BS EN, TAPPI, and GB. With the prestigious CE certification under our belt, VTS products have earned the trust of clients across more than 60 countries worldwide.

Leveraging over 20 years of rich experience, we are adept at swiftly customizing ideal testing solutions tailored to your specific requirements, ensuring your needs are met with precision and expertise.

Our Key Advantages:
With over two decades of expertise, we swiftly provide optimal testing solutions tailored to your specific requirements.
1. Esteemed professional manufacturer with over 20 years of experience
2. Competitive pricing coupled with superior quality and optimal delivery times
3. Comprehensive one-stop solutions for all your material testing machine needs
4. Certified excellence with ISO 9001, SGS, and CE qualifications
5. Enduring lifetime technical support and unparalleled service

Sales Period Service:
Upon receiving your purchase order, we efficiently organize production.
Standard machines are readily available from stock.
For custom-built machines, production spans approximately 2-4 weeks.
We enforce rigorous quality control, ensuring each machine is meticulously inspected prior to delivery.

Comprehensive After-Sales Service:
Our standard warranty period spans one year.
We provide an English operation manual along with an instructional operation video.
Onsite installation and training services are available if required.
