Metallographic Instrument
Automated Metallographic Sample Preparation Machines with Customized Support Options
Available
378Product Description Metallographic Sample Preparation M
| Model NO. | 50mm |
| Type | 0.5 |
| Load Way | Static Load |
| Display | Computer Control |
| Weight | AC380V |
| Oil Cylinder Position | Tensile Test Compression Test, Bending Test etc. |
| Packaging Details | 300kN 500kN 600kN 1000kN 1500kN 2000kN |
| Standard | Metal Materilas, U and V Notch |
| Certificate | Wooden Box |
| Specification | VTS |
| Origin | 9024109000 |
| Production Capacity | 150j 300j 450j 600j 750j |
| Max Load | Pendulum Charpy Impact Testing Machine |
| Testing Machine Mode | OEM |
| Protection Class | 0.5grade |
| Application | <900kg |
| Test Standard | 380V |
| Material | Computer, Digital, Dial |
| Impact Energy |
Metallographic Sample Preparation Machines
1. Application & Features:
In the intricate process of metallographic specimen preparation, the first step is crucial: the cut. Introducing the QG-2 Cutting Machine, perfectly designed for general lithic materials. To ensure an ultra-safe sampling environment, this innovative machine boasts a fully enclosed double-shell structure and a rapid clamping device. Additionally, it features a cooling water tank that recirculates the specially prepared cooling liquid, ensuring optimal sample condition.
To enhance longevity and simplify operation and maintenance, key components such as the enclosure, grinding wheel spindle sleeve, jaw, and operating platform are crafted from durable stainless steel. This makes the machine the optimal choice for precision sample cutting.
2. Main Features:
3. Main Technical Specifications: Discover the pinnacle of precision with the Jinan Victory Instrument Co., Ltd.s state-of-the-art Automated Metallographic Sample Preparation Machines. Tailored to meet your unique needs, these machines are designed to elevate your sample preparation process with unmatched efficiency and reliability. Delve into the technical specifications that define excellence and innovation in metallographic sample preparation.
| Operation Mode | Manual / Automatic, free to choose. |
| Feeding Speed | 3mm/min, 5mm/min, 8mm/min (users may modify the set speed according to requirement) |
| Y axis Maximum Travel Distance | 235mm |
| Z axis Maximum Travel Distance | 35mm(cut style) |
| Maximum Cutting Diameter | Φ65mm |
| Cutting Disc Size | Φ300×2×Φ32mm |
| Capacity of the Cooling Water Tank | 60L |
| Rotating Speed | 500-3000r/min |
| Power Supply | Three-phase Five-wire 380V, 50Hz, 2.2kW |
| Dimensions | 800×760×1370mm |
| Weight | 280kg |
| Model | QGZ-90 |
| Operating Mode | Manual / Automatic |
| Appearance | Metal shell, Explosion proof transparent observation window |
| Cutting Disc Size | Φ300×2×Φ32mm |
| Rotating Speed of Spindle | 500-3000r/min |
| Max. Cutting Ability | Max. Φ90mm Round bar |
| Feeding Method | Horizontal feeding: The motor drives the horizontal screw for cutting feed. The feeding speed can be adjusted of 1-40mm/min. |
| Feeding Mode | Automatic mode--Automatic feeding, it will automatically return to the original when arriving the set position. Manual mode--Slewing hand wheel control or keyboard control (motor driven, manual control). |
| Lifting Travel of the Cutting Spindle | 50mm |
| Lifting Method of the Cutting Spindle | Slewing hand wheel control |
| Y axis Travel | 260mm |
| X axis Travel of the Movable Table | 40mm |
| Cutting Platform | Size: 435×300mm, 12mm groove T type working table |
| Cutting Fixture | Rapid push and pull type vise, one set each for left and right operation. Jaw height: 60mm |
| Key Operation | LCD touch screen and poly dome, Emergency stop button |
| Room Lighting | Built-in LED lighting |
| Cooling System | Three cooling water and one cleaning water |
| Magnetic Filtering Circulating Water Tank | 80L |
| Motor | 3kw Frequency conversion motor |
| Power Supply | 380V, 50Hz |
| Dimensions | 910×935×1350mm |
| Weight | 430kg |
4. Exquisite Imagery of Metallographic Sample Preparation Machines at Our State-of-the-Art Facility
- Precision Notch Cutting Machine Charpy Projector: Advanced Cooling Technology Chamber (-60°C, -100°C): Seamless Liquid Nitrogen Cooling, Achieving -196°C
Jinan Victory Instrument Co., Ltd (Victory Test - VTS) stands out as a prestigious and accomplished manufacturer and exporter, specializing in state-of-the-art material testing machines and exemplary quality control testing equipment. Nestled in Jinan city, the vibrant capital of Shandong province, China, VTS enjoys an advantageous location in the northeast of the country, conveniently situated just a two-hour journey from Beijing and Shanghai. We are passionately committed to providing an all-encompassing solution for our clients Quality Control needs concerning metal materials. Our team, comprising over 50 dedicated professionals with more than two decades of experience, ensures that we deliver expert testing solutions with remarkable promptness.
VTS proudly holds ISO9001 CE certification, affirming its status as a leading high-tech enterprise concentrated on the innovative design, advanced research, meticulous manufacturing, and global marketing of metal materials mechanical property testing machines. Our comprehensive range covers virtually all testing categories, including tensile, compression, bending, torsion, impact, hardness, and fatigue testing. VTS products adhere to esteemed standards such as ISO, ASTM, BS EN, TAPPI, and GB, backed by our CE certification. Our extensive international reach has seen VTS products exported to over 60 countries.
With a rich legacy of over 20 years of experience, we are adept at swiftly providing the perfect testing solution tailored to your specific testing requirements.
Our Advantages:
With over two decades of rich experience, we provide swift and tailored testing solutions, meticulously crafted to meet your precise requirements.
1. We are a professional manufacturer with an impressive legacy spanning over 20 years.
2. Our products blend exceptional quality with a reasonable price, ensuring optimal delivery times.
3. We offer a comprehensive, One-Stop solution for all your material testing machine needs.
4. As an ISO 9001, SGS, and CE certified supplier, we stand for quality and reliability.
5. Enjoy lifetime technical support and unparalleled service, ensuring your peace of mind.
Sale Period Service:
Upon receiving your purchase order, we swiftly mobilize our resources for prompt production.
Standard machines are readily available from stock, ensuring quick availability.
For machines requiring customization, anticipate a production lead time of approximately 2-4 weeks.
We enforce stringent quality controls, with each machine meticulously inspected prior to delivery.
After-Sales Service:
Our warranty period typically extends to one year, offering you reassurance and reliability.
We provide comprehensive English language operation manuals and instructive operation videos.
Should you require it, we can offer onsite installation and training services to ensure seamless operation.
