Metallographic Sample Preparation Machines
1. Application & Features:
We all know that cut is the first working procedure in the preparation of metallographic specimen. The QG-2 Cutting Machine is suitable for the general lithic material. In order to take the sample in ultra-safe situation, the machine not only adopts totally-enclosed double-encloser structure and fast clamp device, but also has cooling water tank, which uses prepared cooling liquid circularly.
For lengthening the service life of this machine and easing its operation and maintenance, the main spare parts such as encloser, grinding wheel spindle sleeve, jaw and operating platform are made of stainless steel. The machine is the best equipment for cutting sample.
2. Main Features:
3. Main Technical Specifications:
| Operation Mode | Manual / Automatic, free to choose. |
| Feeding Speed | 3mm/min, 5mm/min, 8mm/min (users may modify the set speed according to requirement) |
| Y axis Maximum Travel Distance | 235mm |
| Z axis Maximum Travel Distance | 35mm(cut style) |
| Maximum Cutting Diameter | Φ65mm |
| Cutting Disc Size | Φ300×2×Φ32mm |
| Capacity of the Cooling Water Tank | 60L |
| Rotating Speed | 500-3000r/min |
| Power Supply | Three-phase Five-wire 380V, 50Hz, 2.2kW |
| Dimensions | 800×760×1370mm |
| Weight | 280kg |
| Model | QGZ-90 |
| Operating Mode | Manual / Automatic |
| Appearance | Metal shell, Explosion proof transparent observation window |
| Cutting Disc Size | Φ300×2×Φ32mm |
| Rotating Speed of Spindle | 500-3000r/min |
| Max. Cutting Ability | Max. Φ90mm Round bar |
| Feeding Method | Horizontal feeding: The motor drives the horizontal screw for cutting feed. The feeding speed can be adjusted of 1-40mm/min. |
| Feeding Mode | Automatic mode--Automatic feeding, it will automatically return to the original when arriving the set position. Manual mode--Slewing hand wheel control or keyboard control (motor driven, manual control). |
| Lifting Travel of the Cutting Spindle | 50mm |
| Lifting Method of the Cutting Spindle | Slewing hand wheel control |
| Y axis Travel | 260mm |
| X axis Travel of the Movable Table | 40mm |
| Cutting Platform | Size: 435×300mm, 12mm groove T type working table |
| Cutting Fixture | Rapid push and pull type vise, one set each for left and right operation. Jaw height: 60mm |
| Key Operation | LCD touch screen and poly dome, Emergency stop button |
| Room Lighting | Built-in LED lighting |
| Cooling System | Three cooling water and one cleaning water |
| Magnetic Filtering Circulating Water Tank | 80L |
| Motor | 3kw Frequency conversion motor |
| Power Supply | 380V, 50Hz |
| Dimensions | 910×935×1350mm |
| Weight | 430kg |
4. Photos for Metallographic Sample Preparation Machines in our factory
-Notch Cutting Machine Charpy Projector Cooling Chamber(-60,-100) -196, liquid nitrogen cooling
Jinan Victory Instrument Co., Ltd (Victory Test - VTS) is a professional manufacturer and exporter of material testing machines and quality control testing equipment in Jinan city, Shandong province, China. Jinan city is the capital of Shandong province, which is located in the northeast of China (about 2 hours away from Beijing and Shanghai.) We are dedicated to offer one stop solution for customers Quality Control of metal materials. With more than 50 staffs & more than 20 years experience, a professional testing solution can be offered quickly.
VTS is an ISO9001 CE certified high-tech enterprises, who focus on designing, researching, making and marketing on metal materials mechanical property testing machines. The testing machines cover most of the testing items, like tensile, compression, bend, torsion, impact, hardness, fatigue, etc. VTS products can meet ISO, ASTM, BS EN, TAPPI, GB, etc testing standards. We have passed CE certificate, VTS products have been exported to more than 60 countries.
As we have more than 20 years experience, an ideal testing solution can be offered quickly based on your testing requirement.
Our Advantages:
As we have more than 20 years experience, an ideal testing solution can be offered quickly based on your testing requirement.
1. Professional manufacturer for more than 20 years
2. Reasonable price with good quality & best delivery time
3. One-Stop solution for material testing machines
4. ISO 9001 SGS CE etc qualified supplier
5. Lifetime technical support and service
Sale period service:
After we get your P.O., the production can be quickly arranged.
For common standard machine, it is in stock.
For customized produced machine, the production time is about 2-4 weeks.
Strictly control of quality, each machine is well inspected before delivery.
After-sales service:
The warranty period is usually one year.
English language operation manual and operation video are offered.
Onsite installation and training service can be offered if its necessary.
